C# 高性能 Socket 服务器实现与 RabbitMQ 集成详解

在现代网络应用中，构建高性能、可扩展的网络服务器是一个常见的挑战。本文将深入探讨一个基于 C# 的高性能 Socket 服务器实现，程序实现了一个基于 TCP 的高性能异步 Socket 服务器，该服务器接收客户端消息后，通过 RabbitMQ 队列进行消息的异步发送和处理，适合用于需要高并发连接和消息队列集成的实时通信场景。

系统架构

该 Socket 服务器的整体架构包括以下核心组件：

SocketServerOptions：配置管理
HighPerformanceSocketServer：核心服务器逻辑
Program：服务器启动与生命周期管理

配置管理 (SocketServerOptions)

C#
public class SocketServerOptions
{
    public int Port { get; set; } = 8888;         // 监听端口
    public int BacklogSize { get; set; } = 10000; // 连接积压队列大小
    public int BufferSize { get; set; } = 1024;   // 数据缓冲区大小
    public string MqHost { get; set; } = "localhost"; // RabbitMQ 主机
    public string QueueName { get; set; } = "socket_messages"; // 消息队列名称
}

性能优化策略

线程池优化

C#
private void OptimizeThreadPool()
{
    int minThreads = Math.Max(100, Environment.ProcessorCount * 32);
    ThreadPool.SetMinThreads(minThreads, minThreads);
    ThreadPool.SetMaxThreads(minThreads * 2, minThreads * 2);
}

通过动态调整线程池参数，服务器可以根据 CPU 核心数调整线程数量，提高并发处理能力。

并发连接管理

使用 ConcurrentDictionary 实现线程安全的连接管理：

C#
private readonly ConcurrentDictionary<Guid, SocketConnection> _connections
    = new ConcurrentDictionary<Guid, SocketConnection>();

RabbitMQ 集成

服务器通过 RabbitMQ 实现消息解耦和异步处理：

C#
// RabbitMQ 连接初始化
var factory = new ConnectionFactory()
{
    HostName = _options.MqHost,
    AutomaticRecoveryEnabled = true,
    NetworkRecoveryInterval = TimeSpan.FromSeconds(10)
};

// 队列声明，增加可靠性配置
_mqChannel.QueueDeclareAsync(
    queue: _options.QueueName,
    durable: true,
    exclusive: false,
    autoDelete: false,
    arguments: new Dictionary<string, object>
    {
        { "x-max-length", 100000 },     // 队列最大长度
        { "x-message-ttl", 86400000 }   // 消息过期时间
    }
);

连接处理

使用异步处理每个客户端连接，避免阻塞主线程：

C#
private async Task HandleConnectionAsync(SocketConnection connection)
{
    try
    {
        // 读取客户端消息
        while (true)
        {
            int bytesRead = await networkStream.ReadAsync(buffer, 0, buffer.Length);
            if (bytesRead == 0) break;

            string message = Encoding.UTF8.GetString(buffer, 0, bytesRead);
            await SendToMQAsync(message);
        }
    }
    catch (Exception ex)
    {
        _logger.LogWarning($"连接发生错误: {ex.Message}");
    }
}

优雅关闭与资源管理

实现 IAsyncDisposable 接口，确保资源得到正确释放：

C#
public async ValueTask DisposeAsync()
{
    try
    {
        // 关闭所有活跃连接
        foreach (var conn in _connections.Values)
        {
            conn.Socket.Close();
        }
        _connections.Clear();

        _listener?.Close();
        await _mqChannel.CloseAsync();
        await _mqConnection.CloseAsync();
    }
    catch (Exception ex)
    {
        _logger.LogError($"资源释放失败: {ex.Message}");
    }
}

完整代码

Nuget 安装相关包

C#
Microsoft.Extensions.Logging
Microsoft.Extensions.Logging.Console
RabbitMQ.Client

服务端

C#
using System;
using System.Collections.Concurrent;
using System.Net;
using System.Net.Sockets;
using System.Text;
using System.Threading.Tasks;
using Microsoft.Extensions.Logging;
using RabbitMQ.Client;

namespace AppHSocketServer
{
    public class SocketServerOptions
    {
        public int Port { get; set; } = 8888;
        public int BacklogSize { get; set; } = 10000;
        public int BufferSize { get; set; } = 1024;
        public string MqHost { get; set; } = "localhost";
        public string QueueName { get; set; } = "socket_messages";
    }

    public class HighPerformanceSocketServer : IAsyncDisposable
    {
        private readonly ILogger<HighPerformanceSocketServer> _logger;
        private readonly SocketServerOptions _options;
        private Socket _listener;

        // 线程安全的连接管理
        private readonly ConcurrentDictionary<Guid, SocketConnection> _connections
            = new ConcurrentDictionary<Guid, SocketConnection>();

        // RabbitMQ相关
        private readonly IConnection _mqConnection;
        private readonly IChannel _mqChannel;

        // 连接状态追踪
        private class SocketConnection
        {
            public Guid Id { get; set; }
            public Socket Socket { get; set; }
            public DateTime ConnectedAt { get; set; }
        }

        public HighPerformanceSocketServer(
            ILogger<HighPerformanceSocketServer> logger,
            SocketServerOptions options = null)
        {
            _logger = logger;
            _options = options ?? new SocketServerOptions();

            // 初始化RabbitMQ连接
            try
            {
                var factory = new ConnectionFactory()
                {
                    HostName = _options.MqHost,
                    // 添加更多连接配置
                    AutomaticRecoveryEnabled = true,
                    NetworkRecoveryInterval = TimeSpan.FromSeconds(10)
                };

                _mqConnection = factory.CreateConnectionAsync().Result;
                _mqChannel = _mqConnection.CreateChannelAsync().Result;

                // 声明队列，增加更多配置
                _mqChannel.QueueDeclareAsync(
                    queue: _options.QueueName,
                    durable: true,
                    exclusive: false,
                    autoDelete: false,
                    arguments: new Dictionary<string, object>
                    {
                        { "x-max-length", 100000 }, // 队列最大长度
                        { "x-message-ttl", 86400000 } // 消息过期时间24小时
                    }
                );
            }
            catch (Exception ex)
            {
                _logger.LogError($"RabbitMQ初始化失败: {ex.Message}");
                throw;
            }

            // 优化线程池
            OptimizeThreadPool();
        }

        private void OptimizeThreadPool()
        {
            int minThreads = Math.Max(100, Environment.ProcessorCount * 32);
            ThreadPool.SetMinThreads(minThreads, minThreads);
            ThreadPool.SetMaxThreads(minThreads * 2, minThreads * 2);
        }

        public async Task StartAsync()
        {
            try
            {
                _listener = new Socket(AddressFamily.InterNetwork,
                                       SocketType.Stream,
                                       ProtocolType.Tcp);

                _listener.Bind(new IPEndPoint(IPAddress.Any, _options.Port));
                _listener.Listen(_options.BacklogSize);

                _logger.LogInformation($"服务器启动，监听端口 {_options.Port}");

                while (true)
                {
                    var socket = await Task.Factory.FromAsync(
                        _listener.BeginAccept,
                        _listener.EndAccept,
                        null
                    );

                    var clientId = Guid.NewGuid();
                    var connection = new SocketConnection
                    {
                        Id = clientId,
                        Socket = socket,
                        ConnectedAt = DateTime.UtcNow
                    };

                    _connections[clientId] = connection;

                    // 不等待处理，提高并发性
                    _ = HandleConnectionAsync(connection);
                }
            }
            catch (Exception ex)
            {
                _logger.LogCritical($"服务器启动失败: {ex.Message}");
                throw;
            }
        }

        private async Task HandleConnectionAsync(SocketConnection connection)
        {
            try
            {
                using var networkStream = new NetworkStream(connection.Socket);
                var buffer = new byte[_options.BufferSize];

                while (true)
                {
                    int bytesRead = await networkStream.ReadAsync(buffer, 0, buffer.Length);
                    if (bytesRead == 0) break;

                    string message = Encoding.UTF8.GetString(buffer, 0, bytesRead);
                    await SendToMQAsync(message);

                    _logger.LogInformation($"收到客户端 {connection.Id} 消息: {message}");
                }
            }
            catch (Exception ex)
            {
                _logger.LogWarning($"连接 {connection.Id} 发生错误: {ex.Message}");
            }
            finally
            {
                _connections.TryRemove(connection.Id, out _);
                connection.Socket.Close();
            }
        }

        private async Task SendToMQAsync(string message)
        {
            try
            {
                var body = Encoding.UTF8.GetBytes(message);
                await _mqChannel.BasicPublishAsync(
                    exchange: "",
                    routingKey: _options.QueueName,
                    body: body
                );
            }
            catch (Exception ex)
            {
                _logger.LogError($"发送消息到MQ失败: {ex.Message}");
            }
        }

        public async ValueTask DisposeAsync()
        {
            try
            {
                // 关闭所有活跃连接
                foreach (var conn in _connections.Values)
                {
                    conn.Socket.Close();
                }
                _connections.Clear();

                _listener?.Close();
                await _mqChannel.CloseAsync();
                await _mqConnection.CloseAsync();
            }
            catch (Exception ex)
            {
                _logger.LogError($"资源释放失败: {ex.Message}");
            }
        }
    }
}

C#
using System;
using System.Threading.Tasks;
using Microsoft.Extensions.Logging;
using Microsoft.Extensions.DependencyInjection;

namespace AppHSocketServer
{
    class Program
    {
        static async Task Main(string[] args)
        {
            // 创建依赖注入容器
            var services = new ServiceCollection();

            // 配置日志
            services.AddLogging(configure =>
            {
                configure.AddConsole(); // 控制台日志
                configure.SetMinimumLevel(LogLevel.Information);
            });

            // 配置Socket服务器
            services.AddSingleton(sp =>
            {
                var logger = sp.GetRequiredService<ILogger<HighPerformanceSocketServer>>();

                // 自定义配置（可选）
                var options = new SocketServerOptions
                {
                    Port = 8888, // 监听端口
                    BacklogSize = 10000, // 连接积压队列大小
                    BufferSize = 1024, // 缓冲区大小
                    MqHost = "localhost", // RabbitMQ主机
                    QueueName = "socket_messages" // 队列名称
                };

                return new HighPerformanceSocketServer(logger, options);
            });

            // 构建服务提供者
            var serviceProvider = services.BuildServiceProvider();

            // 获取Socket服务器实例
            var socketServer = serviceProvider.GetRequiredService<HighPerformanceSocketServer>();

            try
            {
                // 启动服务器
                Console.WriteLine("Socket服务器正在启动...");

                // 捕获取消操作
                using var cancellationTokenSource = new CancellationTokenSource();

                // 处理控制台退出信号
                Console.CancelKeyPress += (sender, e) =>
                {
                    e.Cancel = true; // 阻止默认的退出行为
                    cancellationTokenSource.Cancel();
                };

                // 启动服务器
                await StartServerWithGracefulShutdown(socketServer, cancellationTokenSource.Token);
            }
            catch (Exception ex)
            {
                Console.WriteLine($"服务器启动失败: {ex.Message}");
            }
        }

        static async Task StartServerWithGracefulShutdown(
            HighPerformanceSocketServer server,
            CancellationToken cancellationToken)
        {
            try
            {
                // 创建一个任务来运行服务器
                var serverTask = server.StartAsync();

                // 等待取消信号
                await Task.Delay(Timeout.Infinite, cancellationToken);
            }
            catch (OperationCanceledException)
            {
                Console.WriteLine("服务器正在关闭...");
            }
            finally
            {
                // 异步释放资源
                await server.DisposeAsync();
                Console.WriteLine("服务器已安全关闭");
            }
        }
    }
}

测试客户端

C#
using System.Net.Sockets;
using System.Text;

namespace AppHSocketClient
{
    internal class Program
    {
        public static async Task Main()
        {
            // 创建多个客户端模拟并发
            var tasks = new List<Task>();
            for (int i = 0; i < 10; i++)
            {
                tasks.Add(SimulateClient(i));
            }
            await Task.WhenAll(tasks);
            Console.ReadKey();
        }

        static async Task SimulateClient(int clientId)
        {
            using (var client = new TcpClient())
            {
                await client.ConnectAsync("localhost", 8888);
                using (var stream = client.GetStream())
                {
                    for (int i = 0; i < 100; i++)
                    {
                        string message = $"Client {clientId} - Message {i}";
                        byte[] data = Encoding.UTF8.GetBytes(message);

                        await stream.WriteAsync(data, 0, data.Length);
                        Console.WriteLine($"发送消息: {message}");

                        // 模拟发送间隔
                        await Task.Delay(10);
                    }
                }
            }
        }
    }
}

应用场景

这种高性能 Socket 服务器适用于：

实时通信系统
日志收集
物联网设备通信
分布式系统消息传输

总结

本文展示了一个 C# 实现的高性能 Socket 服务器，通过线程池优化、并发连接管理和 RabbitMQ 集成，提供了一个可扩展、高效的网络服务解决方案。
